| Storage temperature: | -15˚C to +60˚C |
| Package width [mm]: | 620 |
| Depth / Length of package [mm]: | 530 |
| Package contents: | 1 x UPS 1 x Power cable 1 x RS 232 cable 1 x User manual 1 x Mounting accessories |
| Dimensions (D/L x W x H): | 525 x 438 x 88mm |
| Operating temperature: | 0˚C ~ +40˚C |
| Housing color: | Black |
| Comments: | Network emergency power supplies designed for telecommunications equipment and automatic data processing equipment, the so-called uninterruptible power supply UPS. In the event of a power failure, it provides a "reserve" of energy, thus protecting against loss |
| Additional information: | - possibility of installing a compatible SNMP module: product code 50398 |
| Package height [mm]: | 180 |
| Net weight [kg]: | 16 |
| Gross weight [kg]: | 18 |
| Storage relative humidity: | 20 ~ 95% RH (non-condensing) |
| Communication system: | USB, RS-232, EPO |
| Transfer time: | 0ms |
| Battery charging current: | 1A (default), adjustable 1A-5A |
| Loading device type: | Computers, servers |
| Nominal voltage: | 230VAC |
| Guarantee: | 24 months |
| Certificate: | CE, ROHS |
| Security: | - Against overvoltage - Against overload - Against short circuit - Against high and low voltage |
| Noise level: | ≤ 50dB |
| Output frequency: | 50/60Hz ± 0.05HZ |
| Output voltage: | 230VAC |
| Input voltage: | 110VAC - 300VAC ± 5% |
| Rated power: | 2kVA |
| Power: | 2000W |
| Waveform: | Pure sine wave |
| UPS type: | On-line |
| Built-in battery: | Yes |
| Number of batteries: | 4 |
| Battery voltage: | 12V |
| Application: | Data processing centers; industrial and manufacturing environments; medical centers |
| Display: | LCD |
| Sockets: | 2 x SCHUKO 1 x RS-232 |
| Overload: | Switching to bypass after 4ms |
| Crest Factor: | 3:1 |
| Power factor: | 1.0 |
| Battery pack voltage: | 48V |
| Battery capacity: | 7Ah |
